Stewart Platform

Stewart Platform

6-DoF sophisticated motion system for robotics and controls
ACROME Stewart Platform is a parallel robotic system, could be used for advanced robotics concepts in academia and various applications in industry. It has a default configuration for payload, size and user software.
Request a Quote
Courseware Download
Please fill the form below to reach our product documents. The document will sent you via your email address.
Thank you! Your request is received and we will contact you shortly for the requested file/information.
Oops! Something went wrong while submitting the form.
Product Media

REFERENCE CUSTOMERS

boing logo
jaguar and land rover logos

OVERVIEW

Stewart Platform can offer realistic simulations at six-axis owing to the high sensitivity of linear actuators, gyroscope, and a three-axis accelerometer. With the accessible and user-friendly components, it is suitable to simulate real systems such as flight simulators, machine tool technology, crane technology, mechanical bulls, precision platform positioning such as telescopes, antennas, and orthopedic surgery. Every unit of the Stewart platform is controllable independently with the modifiable open-source software and users can understand the effects of different controller types on the system. With the extensive courseware, users have the opportunity to learn essential aspects of robotics and easily cover controller design concepts.
lifetime support badge
online installation badge
user friendly interface badge
free shipping badge

SMD PRODUCTS

SMD - RED

Smart Brushed Motor Driver with Speed, Position and Current Control Modes

$79.00
Buy From RobotShop

SMD - Starter Kit

For SMD RED Smart Brushed Motor Driver (Recommended for New Users)

$210.00
Buy From RobotShop

SMD - Education Kit

For Teaching Robotics, Sensors, and Actuators

$1,200.00
Buy From RobotShop

SOFTWARE OPTIONS

LabVIEW, Real-Time (optional), FPGA (optional)
Altair Activate
Executable & GUI
Python
LabVIEW, Real-Time, FPGA (optional)
Python and OpenCV
API for External Control (Examples for LV, Matlab, Python)
MatLab/Simulink
C with STM32 software
API for External Control (Examples for LV, Matlab, Python)
* Different controllers may require

CONTROLLER OPTIONS

USB (PC based)
Raspberry Pi + Shield
NI myRIO
Arduino Mega + Shield

APPLICATION AREAS

Professional Photography
Medical Applications
Wearable Items
Quality Assurance
Engineering Research Applications
Positioners' Algorithm Research
Starting From
$7,499
Stewart platform
Ready to use GUI
API for external programming
Customization options available
REQUEST A QUOTE

PRODUCT PHOTOS

SPECIFICATIONS

Standard Unit
Customizations Options
Payload
12 kgs (26,5 lbs)
Up to 150 kgs (331 lbs)
Workspace Options
X and Y Axis +/-60 mm
Z Axis +/-50 mm
Roll, Pitch, Yaw +/- 20°
Up to +/-300 mm
Up to +/-150 mm
Up to +/- 45°
Position Repeatability
+/- 100 µm
Down to +/- 25 µm
Angular Sensitivity
0.2°
Down to 0.1°
Max. Linear Speed
40 mm/sec.
Up to 80 mm/sec.
Height (min-max)
406-506 mm
330-920 mm
Platform Diameter
350 mm (hexagonal)
250-1000+ mm
Base Diameter
450 mm (hexagonal)
450-1000+ mm
Weight
14 kgs (31 lbs)
Based on custom options
No items found.

FEATURES

Ready to use product with integrated power unit, controller and software

Ready-to- and easy-to-use Graphical User Interface software for quick start

Built-in API for custom software development and test automation

Compatible with MATLAB®/Simulink®, LabVIEW™, Python and C/C++

Six independent controllable actuators having built-in position feedback sensors

Built-in kinematics solver. Users need to enter the desired coordinates only

Real-time measurement of the Platform via the aux. Inertial Measurement Unit (IMU) sensor

Precision-crafted plates with standard or custom mounting holes

Open source software option to create your own algorithm or teach/learn parallel kinematics

Virtual pivot point setting, oscillation and playback modes available in software.

FAQs

What is Stewart Platform?
The Stewart Platform is a 6-Degrees of Freedom precision parallel robotic positioner system. It is capable of moving in X, Y, Z and Roll, Pitch, Yaw coordinates.
What is a Stewart Platform used for?
A Stewart Platform is used for positioning its upper or lower plate using its electromechanical actuators. Typical applications are alignment, leveling or placement of materials or executing a repeatable / random motion such as vibration or oscillation pattern to an object mounted on either of its plates.
How many degrees of freedom does a Stewart Platform have?
6-DOF. These are X,Y,Z, rotation around X, Y, Z ie. roll, pitch, yaw.
Does the product comes with a controller and software/courseware?
Product comes with the controller and software. Courseware is optional with choice of the programming language.
Can I use a custom motion pattern? How?
A custom motion pattern can be implemented via a scenario script or through importing a CSV file with timestamp and coordinates data. Necessary information is provided in the User's Manual.
Is there any after-sales support or training for the product?
A complimentary online support session is available after the delivery of the products. Standard support is provided via the phone, e-mail or remote desktop connection.

CURRICULUM

INTRODUCTION
Definition of a Robot
Parallel Manipulators and Stewart Platform
Uses of Stewart Platforms
COMPONENTS OF STEWART PLATFORM
Linear Actuator with Feedback
Controller
Six-Axis Gyro+Accelerometer
Motor Driver
ACROME Power Distribution Box
PARALLEL KINEMATICS
Joint Description
Inverse Kinematics
Mobility of Stewart Platform
TRAJECTORY GENERATION
Introduction
General Considerations in Path description and Generation
Cartesian Space Schemes
Joint Space Schemes
Cubic Polynomials
Cubic Polynomials for a Path with via Points
Higher Order Polynomials
Linear Function with Parabolic Blends
Linear Function with Parabolic Blends for a Path with via Points
